RAF Waddington.
E-3D Sentry based at RAF Waddington

RAF Waddington is located south of Lincoln in Lincolnshire, and is home to the Royal Air Force's Intelligence Surveillance Target Acquisition and Reconnaissance (ISTAR) aircraft.

Aircraft operated by RAF Waddington include the E-3D Sentry AEW1, RC-135W Rivet Joint, Beechcraft Shadow R1 and the MQ-9 Reaper.

RAF Valley Satellite View

Military Aircraft Tracker in the UK
Current Military Aircraft in the UK Tracker.
Historic Military Aircraft in the UK Tracker.
Military Aircraft around the World Tracker.

Live Trackers
Plane Finder tracks mainly civilian flights but does also include some military aircraft such as the Tutor, Tucano, Hawk, Voyager, BAe 146, Squirrel HT1, and Sentinel R1 etc which can be seen over the UK. ADS-B Exchange (Click on ADSBX Radar View) tracks many other military aircraft such as Tornado, Typhoon, F-15, Hercules etc over the UK.

Scanner Frequencies

RAF Waddington Scanner Frequencies
CAC (Swanwick Mil) - 275.500
Approach - 345.075, *362.300
Zone - 119.500, 232.700
Director - 280.175, *123.300
PAR - 344.200, 231.800
Tower - 241.325, *257.800, 121.300, *121.100
Ground - 342.125
OPS - 369.400
ATIS - 291.675
*= NATO Common Frequency

Military Aircraft Photographs at UK Military Bases

Add Your Photographs

Aircraft & Squadrons
RAF Waddington is home to RAF Air Command surveillance and reconnaissance assets. Waddington's operational flying Squadrons include 8, 13, 14, 39 and 51 which use the E-3D Sentry AEW1, MQ-9 Reaper, Shadow R1 and RC-135W Rivet Joint aircraft.

The Sentinel R1 was an airborne battlefield and ground surveillance aircraft which was retired in March 2021. The E-3D Sentry AEW1 is an airborne early warning and control aircraft (final flight in August 2021). *The MQ-9 Reaper is a medium-to-high altitude, long endurance remotely piloted aircraft system. The Shadow R1 is an ISTAR asset which improves a military commander's awareness of what is happening on the ground or in the air. The Rivet Joint aircraft is equipped with a variety of sensors, allowing its multi-disciplined crew to intercept and exploit emissions across the electromagnetic spectrum, providing both strategic and tactical level intelligence.

Other Squadrons based at Waddington include 54(R) Sqn which is an Operational Conversion Unit for training on Waddington's various aircraft, 56(R) Sqn is for test and evaluation which is part of the Air Warfare Centre, and 92 Sqn which provides air training and tactics advice, 2503 Sqn who defend RAF installations against any potential enemy. 7006 Sqn RAuxAF, 7010 Sqn RAuxAF, 7630 Sqn RAuxAF are also based here, as well as the 'Air Battlespace Training Centre' and 'Air Warfare Centre'. 216 Squadron reformed on 1 April 2020, initially being based at Waddington and will operate as an experimental unit that will test future drone swarm technology. The Lincolnshire & Nottinghamshire Air Ambulance (MD-902 Explorer) is also based at Waddington.

*The ten MQ-9 Reapers will be replaced by an initial sixteen MQ-9B Protector remotely piloted aircraft which is to start entering service by mid-2024. These will be operated by 31 Squadron from RAF Waddington (31Sqn was at RAF Marham and operated the Tornado GR4) and XIII Squadron. The Protector has a maximum operating altitude of 45,000 ft (compared with 50,000 ft for the Reaper), a maximum endurance of more than 40 hours (compared with 27 hours for the Reaper), a maximum air speed of 200 kt (compared with 240 kt for the Reaper) and can operate in busy unsegregated civilian airspace. It also has nine external stories stations, compared with five for the Reaper. Equipment for Predator includes multispectral targeting systems and AN/APY-8 Lynx IIe Block 20A synthetic aperture radar and ground moving target indicators (SAR/GMTI), as well as enhanced datalinks. Munitions comprise MBDA Brimstone 3 missiles and Raytheon Paveway IV laser-guided bombs. A SkyGuardian aircraft, a pre-production example of the new Protector Remotely Piloted Aircraft System (RPAS), will operate from RAF Waddington and later RAF Lossiemouth from 20 August 2021 to 15 October 2021. Operating in the UK will assist in the development of the revolutionary Detect and Avoid technology which will permit Protector to fly in all UK airspace safely.

5(AC) Squadron - Sentinel R1.
8 Squadron - Sentry E-3D.
13 Squadron - MQ-9 Reaper.
14 Squadron - Shadow R1.
39 Squadron - MQ-9 Reaper (Creech AFB, USA).
51 Squadron - RC-135W Rivet Joint.
54(OCU) Squadron - Sentry, Shadow, Rivet Joint & Poseidon.
56(Test and Evaluation) Squadron - Sentry.
216 (Experimental Unit) Squadron - Testing future drone swarm technology.

The RAF E-3D Sentry was retired in August 2021, as part of the transition to the more modern and more capable fleet of three E-7A Wedgetail aircraft in 2023. See the Strategic Defence and Security Review. On 30th July 2021, the RAF E-3D Sentry flew its final operational mission which saw it supporting the Queen Elizabeth Strike Group Pacific Deployment, Op Shader and NATO assurance missions - it returned home to RAF Waddington for the last time on Wednesday 4th August 2021 at about 3pm. Full story:

The Sentinel R1 and 5(AC) Squadron were retired at the end of March 2021. It was also announced in 2020 that RAF Waddington has been selected as the only viable alternative basing location for the Royal Air Force Aerobatic Team (RAFAT) - the RAF Red Arrows.

It was announced in November 2021 that the Shadow R1 fleet will be increased from 6 to 8 aircraft which will receive the latest defensive technology.

Waddington opened as an RFC training station in 1916, and transferred to the Royal Air Force when they were formed in 1918, until 1920, when the station was closed and went into care and maintenance.

RAF Waddington reopened in 1937 after being developed into a fully equipped Bomber Station. It was equipped with Hawker Hinds, Handley Page Hampdens, Bristol Blenheims, and Avro Anson. In 1940, the station received the Avro Manchester heavy bomber, and in 1942, were the first in RAF Bomber Command to operate the Lancaster.

In 1957, Waddington became an Avro Vulcan V-bomber base until 1968 when the UK nuclear deterrent passed to the Royal Navy with their Polaris submarines. During the Falklands War, three of Waddington's Vulcans and crews were involved in the bombing raid on Port Stanley airfield (Operation Black Buck).

In the mid-1980s, Waddington became home to a few NATO AWACS aircraft and the RAF used these aircraft until it bought it's own AWACS fleet in 1991.

RAF Waddington hosted the largest Royal Air Force air show until its cancellation in 2015. The last air show at RAF Waddington took place in 2014, and it will not return again due to 'significant security concerns and operational risks'.


RC-135W Rivet Joint - Simon Oldfield.RC-135W Rivet Joint - Simon Oldfield.

Beechcraft Shadow R1.Beechcraft Shadow R1 - Wikimedia Commons.

Sentinel R1.Sentinel R1.

E-3D Sentry AEW1 & Fighters.E-3D Sentry AEW1 & Fighters.

MQ-9 Reaper.MQ-9 Reaper - Wikimedia Commons.

RAF Protector UAV.RAF Protector UAV.

A look at the RAF Protector UAV:

Vulcan To The Sky Calendar 2022

Red Arrows Official Calendar 2022

Buy Airband Scanners at Amazon.

RAF Waddington will be home to the Red Arrows:
Red Arrows.

Red Arrows News
Red Arrows will relocate to RAF Waddington...
